10.24kwh/1305w solar
Medium solar light vehicel
| Lighting System | 6*120W LED Floodlights |
| Light Output | 144000 Lumens, 200LM/W |
| Lighting range | 2572.5m² @5Lux |
| Spring Cables | 6*2.5mm² +6*1.5mm² |
| Solar Panel Type | Monocrystalline Silicon |
| Solar Panel Wattage | 4*435 W |
| PV Controller | Victron MPPT 50A, 95% efficiency |
| Battery Type | LiFePO4 |
| Battery Pack | 4*100 AH, DC 51.2V |
| Battery Capacity | 20.48 KWH |
| System Voltage | DC 51.2V |
| Maximum Height | 7.5 Meters |
| Wind Resistance Rating | 1 17 KM/H |
| Lifting System | Manual / Electric/Hydraulic |
| Axle Qty | Single |
| Tyre and Rim | 14 Inch |
| Support Leg | 4pcs, Manual |
| Tow Hitch | 50 mm Ball/ 70 mm Ring |
| Working Temperature | -20°C-+60°C |
| Charging Time | 15 Hours |
| Running Time | 23 Hours |
| Optional | AC Battery Charger, inverter, Diesel Generator, Wind Turbine |
| Transport Dimensions | 2200*1500*2300 mm |
| Operating Dimensions | 5200* 3550*8000 mm |
| Gross Weight | 1600 KG |
| Container Loading | 40 GP: 7 pcs |
